Home Products FPC/FFC Connectors 110001-20XX50

110001-20XX50

1.0-3 Series、1.0mm、NON-ZIF、Vertical（SMT）、Vertical、Front-row

Drawing Download all materials

Related parameters

ZIF / Non-ZIF

Non-ZIF
Offset Terminal Design

Front-row
Rated Current

1.0 A
Rated Voltage

50 V
Operating Temp. Range

-40°C ~ 105°C
Contact Position

Dual Contact
FPC/FFC Insertion Direction

Vertical
Mount Type

Vertical（SMT）
Locking Mechanism

No lock
Pin Count

4 ~ 40
Pitch

1.0 mm
Note

Natural

Download

Drawing 2023-06-01
340.79 KB
Download Now
