Home Products FPC/FFC Connectors 101074-20XX50

101074-20XX50

With Latch，anti-disconnection mechanism for FFC assembly，flip-lid design；
terminals with high resilience，double spring-arm double contact，excellent shock resistance；
Stacking Height 2.50mm， Pitch 0.5mm ，ZIF

Download all materials

Related parameters

Soldering Pin Position
Rated Current

0.5A
Rated Voltage (DC)

50V
Rated Voltage (AC)

50V
Operating Temperature

-40°C ~ 105°C
Contact Position
FPC/FFC Insertion Direction

Horizontal
Connector Length
Connector Width
Connector Height

2.5mm
Applicable Wire

1.0mm Detent latch
Mount Type

Horizontal（SMT）
Locking Mechanism

Front flip
Pin Count

6-70
Connector Type

FPC/FFC Connector

Download

Drawing

381.29 KB

Download Now
