Home Products FPC/FFC Connectors 101077-20XX50

101077-20XX50

Download all materials







*4PIN 镀金

Related parameters

ZIF

ZIF
Soldering Pin Position
Rated Current

1.0A
Rated Voltage

50V
Operating Temperature

-40°C ~ 105°C
Contact Position

Bottom Contact
FPC/FFC Insertion Direction

Horizontal
Connector Length
Connector Width
Connector Height

2.5mm
Applicable Wire
Mount Type

Horizontal（SMT）
Locking Mechanism

Front flip
Pin Count

12
Connector Type

FPC/FFC Connector
Pitch

1
Note

Download

Product Drawings

2023-06-01

1.21 MB

Download Now
