Home Products FPC/FFC Connectors 101110-20XX50-HF

101110-20XX50-HF

0.4-5 Series、0.4mm、ZIF、Horizontal（SMT）、Front flip、120Pin

Drawing Download all materials



Related parameters

FPC/FFC Insertion Direction

Horizontal
Offset Terminal Design

——
Rated Current

0.4 A
Rated Voltage

50 V
Operating Temp. Range

-40°C ~ 105°C
Contact Position
Mount Type

Horizontal（SMT）
Locking Mechanism

Front flip
Pin Count

70 ~ 120
Pitch

0.4 mm
Note

Download

产品图纸 2023-06-01
760.15 KB
Download Now
