Home Products FPC/FFC Connectors 101059-20XX50

101059-20XX50

0.5-21A Series、0.5mm、ZIF、Vertical（SMT）、Side flip、Rear-row

Drawing Download all materials

Related parameters

ZIF / Non-ZIF

ZIF
Offset Terminal Design

Rear-row
Rated Current

0.5 A
Rated Voltage

50 V
Operating Temp. Range

-40°C ~ 105°C
Contact Position
FPC/FFC Insertion Direction

Vertical
Mount Type

Vertical（SMT）
Locking Mechanism

Side flip
Pin Count

10 - 70
Pitch

0.5 mm
Note

Download

Drawing 2023-06-01
548.92 KB
Download Now
