Home Products FPC/FFC Connectors 101072-20XX50

101072-20XX50

0.5-15C Series、0.5mm、ZIF、Horizontal（SMT）、Front flip、 Dual Contact

Drawing Download all materials

*101072 60Pin 镀半金锡

Related parameters

ZIF / Non-ZIF

ZIF
Offset Terminal Design

——
Rated Current

0.5 A
Rated Voltage

50 V
Operating Temp. Range

-40°C ~ 105°C
Contact Position

Dual Contact
FPC/FFC Insertion Direction

Horizontal
Mount Type

Horizontal（SMT）
Locking Mechanism

Front flip
Pin Count

6 - 64
Pitch

0.5 mm
Note

Download

Drawing
622.8 KB
Download Now
