Home Products FPC/FFC Connectors 101026-20XX50

101026-20XX50

Download all materials







Related parameters

ZIF

ZIF
Soldering Pin Position
Rated Current

1.0A
Rated Voltage

50V
Operating Temperature

-40°C ~ 105°C
Contact Position

Bottom Contact
FPC/FFC Insertion Direction

Horizontal
Connector Length
Connector Width
Connector Height

2.7mm
Applicable Wire

Non-latch type
Mount Type

Horizontal（SMT）
Locking Mechanism

Rear flip
Pin Count

8 ~ 30
Connector Type

FPC/FFC Connector
Pitch

1
Note

Download

Product Drawings

232 KB

Download Now
