0.5-10 Series

0.5-10 Series、0.5mm、ZIF、Horizontal（SMT）、Slider、Upper Contact / Bottom Contact

Viewing Series Products

Related parameters

ZIF / Non-ZIF

ZIF
Offset Terminal Design

——
Rated Current

0.5 A
Rated Voltage

50 V
Operating Temp. Range

-40°C ~ 105°C
Contact Position

Upper Contact / Bottom Contact
FPC/FFC Insertion Direction

Horizonta
Mount Type

Horizonta（SMT）
Locking Mechanism

Slider
Pin Count

4 - 50
Pitch

0.5 mm
Note
Remark

IRISO 9682 series ; Kyocera 6392 series
